Dream Amplifier

SPA-8 Playback Designs Stereo Power Amplifier

Features

• ultra-low-noise differential linear-phase input
• discrete complementary differential class-A input stage
• discrete complementary class-A voltage amplifier stage
• class-A pre-driver and driver
• class-AB bipolar output stage
• low impedance CFP bias generator
• latest thermal TRAK technology for ultra-fast and precise bias
• 20x 200W BJ transistors per channel
• 2x 1800VA toroidal transformer with electric and magnetic shielding
• 294000µF capacitors
• each channel is a standalone processor supervised system (total of four processors)

Specs

• 2x 1600W continuous peak into 4 Ohm
• 0.00054% THD+N (1kHz, 400W, 8R)
• 93dB SNR (1W, 8R, 20Hz-22kHz)
• 860x730x340 (LxBxH[mm])
• 137kg
